JUST THE FACTS:

The 29mm PressFit 30A bottom bracket works with all DUB Road crank sets on the market. The "A" in PF30A stands for asymmetric, and refers to the way the frame is offset to the non-drive side. All of our modules ship with the special press tools and retaining compounds you'll need. All you need is the press.

All 2016 and up SuperSix Evo Hi-Mod and Black Inc. models and ALL 2017 and up Evo RegMods are PF30A. All 2018 and up SystemSixes and all 2016 and up Slice/Slice HiMods are PF30A as well. NOTE: These bikes say "BB30" on the frame, yet they are PF30A.

ABOUT OUR BEARING CHOICES:

Ceramitech Bearings: Our Si3n4 hybrid ceramic bearings feature ultra-spherical silicon nitride balls matched to SAE 52100 chrome steel bearing races that have been processed with additional heat treatment and polishing steps. The result is a hybrid-ceramic bearing that lasts longer than any steel bearing with spin performance no steel bearing can rival. We’re so confident in the durability of our Ceramitech bearings that we back them with a Lifetime Bearing Exchange warranty. These bearings feature mid-contact seals for extreme performance and endurance. Each bearing comes lubricated with Kluber Isoflex Topas NB52. Lifetime Warranty.

WS2 Coated Ceramitech Bearings: We took our amazing Ceramitech bearings and added an extremely durable, tungsten disulfide (WS2) coating that has a 0.03 coefficient of friction---which means it’s slicker than Teflon, graphite, and even molybdenum disulfide. WS2 has an affinity for oils and greases, which means it maintains a hydrodynamic layer of lubricant where it’s needed most. The result is astonishing spin performance and increased endurance. These bearings feature mid-contact seals for extreme performance and durability. Each bearing comes lubricated with Kluber Isoflex Topas NB52. Lifetime Warranty.

ABEC-7 Steel Bearings: Crafted from SAE 52100 chrome steel, our BBInfinite ABEC-7 (ISO 492, Class 4) bearings are so buttery that you’d have to buy our Ceramitechs to find anything better. These bearings feature mid-contact seals for extreme performance and durability. Each bearing comes lubricated with Kluber or Koyo. 1-Year Bearing Exchange Warranty.

MORE THAN EXTREME SPEED AND SILENCE:

The PressFit 30A bottom brackets for DUB road cranksets maintain optimal chain-lines for crisp, consistent shifting and drive train performance while dishing out trouble-free mile after trouble-free mile. From the gorgeous, high-luster of our TypeII MilSpec hard anodized finish, to the sculpted lines of our One-Piece Design, every aspect of our architecture fuses beauty with durability and performance.

Our DUB spindle optimized design is set to the widest stance the crank format allows while ensuring that interfaces between crank arm splines and spindle splines have maximum engagement and Q-factor is set as narrow as possible.

POWER METER FRIENDLY

The PressFit 30A bottom bracket for DUB road crank sets are 100% compatible with all crank-based power meters. Our flange-less drive-side architecture ensures zero interference with protruding power-meter back plates such as those found on Quarqs and SRMs.

WHY DO BBINFINITE BOTTOM BRACKETS SPIN LIKE CRAZY?:

Bicycle frame bottom bracket shells are notoriously misaligned, inconsistent, and out of round, and so it’s inadvisable to use the bike frame as the primary aligning member for bottom bracket bearings. Yet, that’s what our multi-piece bottom bracket competition does, and this explains why their systems frequently fail prematurely and creak.

A BBInfinite OPD (One-Piece-Design) bottom bracket module is a CNC precision-machined hub---like the front wheel hub on your bike---that you press into your frame. And just like your trouble-free wheel hub, BBInfinite OPD bottom brackets have perfectly aligned bearings regardless of your frame’s BB shell alignment and tolerances. Perfectly aligned bearings are essential for thousands of miles of trouble-free use and extreme spin performance.

WHAT KEEPS BBINFINITE BOTTOM BRACKETS FROM CREAKING?

BBInfinite OPD is the answer for creaking bottom bracket problems as well. Pedaling forces conspire to lever, and rock, and eventually work multi-piece systems loose. The unitized nature of BBInfinite OPD cancels these forces out entirely, which means creaking has no place to start in the first place. It really is that simple.

INSTALLATION IS A SNAP WITH BBINFINITE:

All BBInfinite OPD bottom brackets ship with the special press tools, hardware, instructions, and the retaining compound you need to get the job done correctly with ease and confidence. All you need is the press. If you need a press, check out our Master Tool Press.

BB Standard

SRAM Part Number

BBInfinite Part Number

Common Fitment Examples

PF30 road (68mm x 46mm)

00.6418.018.000

PF30-DUB-RD

Cannondale SuperSix Evo Gen1, Parlee Altum

PF30A (73mm x 46mm assymmetrical)

00.6418.028.001

PF3A-DUB-RD

Cannondale SuperSix Evo Gen2, Cannnodale Slice

PF30 MTB (73mm x 46mm)

00.6418.028.001

PF30-DUB-MT

Cannondale Scalpel Gen1

OSBB road (61mm x 46mm)

00.6418.018.000

OSBB-DUB-RD

Specialized road bikes only (2015-up bikes have BB30 cups epoxied-in

OSBB MTB (73mm x 46mm)

00.6418.028.001

OSBB-DUB-MT

Epic, Stumpjumper, etc (similar to PF30 Mtb, but there is a difference)

BBRight (79mm x 46mm assymmetrical)

00.6418.028.001

BBRT-DUB-RD

Cervelo S5 Gen1 and 2, Factor ONE

BB386 Evo (86.5mm x 46mm)

00.6418.026.000

86EV-DUB-RD

Wilier Cento1 SR, Orbea Orca Aero, Specialized Diverge

BB86/PF86 (86.5mm x 41mm)

00.6418.025.000

BB86-DUB-RD

Bianchi Oltre XR4, Giant TCR Adv., Scott Addict

BB92/PF92 (92mm x 41mm)

00.6418.025.000

BB92-DUB-MT

Yeti Cycles SB5.5 Carbon, Giant Anthem

BSA30 (English threaded, 68mm)

00.6418.015.000

BENG-DUB-RD

Any English threaded( 1.37" x 24 TPI) road frame shell

BSA30 MTB (English threaded, 73mm)

00.6418.015.000

BENG-DUB-MT

Any English threaded( 1.37" x 24 TPI) road frame shell

BB30 (68mm x 42mm)

00.6418.017.000

coming soon

CAAD10

BBB30A (73mm x 42mm assymmetrical)

00.6418.027.000

coming soon

CAAD12, Synapse Carbon

BB30 MTB (73mm x42mm)

00.6418.027.000

coming soon

Any BB30 MTB frameset
Technical Specifications

Weight:

WS2: 108g | CERAMITECH: 110g | ABEC-7 SS: 115g

Frame Width: 73mm

Frame Diameter: 46mm

Spindle Diameter: DUB
