BBInfinite Pro Tip: Tubeless Conversion Rim Taping Done Right VIDEO 1

December 27, 2022



Which type of bottom bracket module do I need?? Email us at info@bbinfinite.com and let know the bicycle frame type (e.g. road), frame manufacturer, frame model and model year, and crank type (manufacturer and model), and with this information we'll reply with a link directly to the product you need. Attach a few pictures showing the crank and bottom bracket area clearly, and one of the entire bicycle to aid us in our quest to get you on the right track. Creaking Bottom Bracket Section My bottom bracket is creaking and I've tried everything to fix it. How does a BBInfinite Bottom Bracket module fix a creaking problem? We fit creaking bottom brackets with proper engineering and precision machining. Watch this brief BBInfinite primer PressFit Perfection to get the lowdown on how we do it while all others fail. I heard that PressFit bikes just creak. Is that true? No, that is completely false information. PressFit bottom brackets offer the potential for the highest level performance possible, thanks to BBInfinite. There is no reason for your PressFit bike to creak, crunch, crack, or make any noises at all. Unless the frame is cracked the bike will be quiet. Can a creaking and popping bottom bracket damage my frame? Yes, it can. A creaking bottom bracket means there's movement between the bottom bracket and the frame. The more a bottom bracket creaks the more it is moving. This movement over time can wallow out the frame bottom bracket shell openings, enlarging them and elongating them, making them more susceptible to creaking and making it impossible to fit new bottom brackets. Don't freak out, it takes a long time. We've seen only a handful of bikes go in the junk heap due to bottom bracket shell ovalization. Install a BBInfinite module to save your frame, and your sanity. General Bottom Bracket Information Section: How much do the modules weigh? Each module model has its weight published under the product description. Go to the BBInfinite bottom bracket page for the type of bottom bracket you desire and you'll find a series of tabs in the product description area. The "info" tab is open already. The last tab "specifications" is where you'll find the product weight along with it's external dimensions. Do all BBInfinite Modules have bushings in the middle? No. Only modules designed for a 30mm spindle require a bushing due to variances in 30mm crank set design and "set up" from one manufacturer to another. These inconsistencies are mostly in the area of preload adjustment methods that put too much side load on the bearings. These over-preloading situations require the use of a bushing between the inner races of each bearing to ensure proper performance. Shimano DirectFit and Campagnolo DirectFit models do not need a bushing. GXP modules have a short bushing that reduces the bearing diameter on one side, but it is not a full length version found on BBInfinite 30mm crank spindle models.. Can I use adaptors with a BBInfinite Module? We'd rather you didn't. Technically, it is possible, but such action departs from the basic principles of BBInfinite engineering methodology. Adaptors cause creaks and bearing alignment problems, and are unnecessary when you can select the proper BBInfinite Module for your frame and crank set for a creak-free, high performance riding experience. How long do the bearings last? It varies. Road applications typically last 8,000-12,000 miles for steel bearings and 8,000-12,000 miles for Ceramitech bearings. MTB applications are entirely dependent upon conditions, especially water exposure. Example: A Category 1 MTB racer can usually go an entire season, racing a full schedule, on a single set of bearings of either type. Ceramitechs are better in wet conditions due to a high degree of corrosion resistance. Will a BBInfinite Module work with my power crank/power meter? Absolutely. We designed them specifically to be compatible with even the somewhat troublesome-to-fit older model SRM cranks. BBInfinite Modules are compatible with all power cranks/power meters. Are BBInfinite Modules compatible with my Rotor Qrings / Osymetric rings? Absolutely. BBInfinite Modules are compatible with all chain rings; be they round, not-so-round, or almost square.



Setting up a wheel tubeless can be quick, easy, and clean, and I'm about to show you how to do it like a pro. Whether it's a new rim, or an old rim, you gotta get it perfectly clean so the tape will stick. For that you need a little bit of alcohol, Scotchbrite pad, and get to work, to make sure you got it clean, use a white paper towel soaked in alcohol, and rub it on there. Keep working until it comes back perfectly clean. It's good practice to always round the nose of your tape, and what this does, is it keeps from having little edges that can get caught and start lifting. Locate your valve hole, and move up about two spoke holes, or about six inches, and begin your taping. Lay the tape in the valley nice and straight, and then get it stuck down, and now the fun begins. Now that I have the tape laid into the valley, I'm going to put my hand here to hold it in place because I'm going to draw a lot of pressure on it. Don't punch yourself in the face if you slip. But you wanna keep that tension on there and watch the way that thing goes, sucks right down into the valley. Just by putting on about 25 or 30 pounds of pressure. As we get close to the end, what we want to do is go past where were laid that tape in to start. We wanna go past that, and the valve hole, as I can feel it back here. You wanna go past that about two spoke holes like we did before, or at least 6 inches, and then you want to cut. Alright, then to terminate we just want to round our edges, and push this right down where it belongs. Now you want to find where your valve hole is. Confirm it is, you don't want to accidently poke where the spoke hole is, and then you're going to wanna kinda just probe in here a little bit until you find it and cut a very small cross notch in it. Just like that. And then push the valve through and tighten the nut down. So that was easy; we got the rim taped without a problem. Now we need to mount our tire, add the sealant, and get this thing pumped up, and I'm going to show you how to do that in our next video and it's going to be clean, quick, and we're gonna do it like a pro.
